Product Code

Product Image

Product Specifications

Product Description

View details

Drawing

42501W00

42501W90

42501H00

42501TOP

0.098"180°Dual WAFER DIP TYPE

0.098"90°Dual WAFER DIP TYPE

0.098"Double wire end rubber shell

0.098"amphenol connector

PIN:2*2-2*10P H:12.45MM

PIN:2*2-2*10P H:11.80MM

PIN:2*2-2*10P H:11.30MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details View details

42501H00

42501H00

32501TOP

0.098"Double wire end rubber shell

0.098"Double wire end rubber shell winged

0.098"amphenol connector

PIN:6P 8P 10P 12P 16P 20P H:30.6MM

PIN:6P 8P 10P 12P 16P 20P H:30.6MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details

42502W00

42502W90

42502H00

42502TOP

0.098"180°Dual WAFER DIP TYPE

0.98"90°Dual WAFER DIP TYPE

0.098"Double wire end rubber shell

0.098"amphenol connector

PIN:2*4-2*20P H:10.10MM

PIN:2*4-2*20P H:12.10MM

PIN:2*4-2*20P H:12.0MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details View details

42503W90

42503W00

42503H00

42503TOP

0.098"90°Dual WAFER DIP TYPE

0.098"180°PITCH WAFER DIP

0.098"Double wire end rubber shell

0.098"amphenol connector

PIN:2*3-2*10P H:14.95MM

PIN:2*3-2*10P H:15.50MM

PIN:2*3-2*10P H:15.45MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details View details

32503H00

32503TXP

42503H00

42503TOP

0.098 0.098"Double wire end rubber shell

0.098"amphenol connector

0.098"Double wire end rubber shell

0.098"amphenol connector

PIN:2*3-2*10P H:23.20MM

Material：Phosphor Bronze Plating：Au or Sn

PIN:2*3-2*10P H:15.45MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details View details

42504W00

42504H00

42504B00

42504TXP

0.098" 180°PITCH WAFER DIP

0.098"Single wire end rubber shell

0.098"Positioning buckle

0.098"amphenol connector

PIN:1*2P-1*10P H:18.80MM

PIN:1*2-1*10P H:12.0MM

 PIN:1*2-1*10P H:7.8MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details View details

42505W90

42505H00

42505H01

42505TOP

0.098"90°Dual WAFER DIP TYPE waterproof

0.098"Double wire end rubber shell waterproof

0.098"Double wire end rubber shell waterproof

0.098"amphenol connector

PIN:18P 26P 34P 40P H:18.30P

PIN:2*1~2*5 H:15.45P

PIN:2*3~2*10 H:26.35P

Metal material: Brass/high conductivity copper

View details View details View details View details

42507W00

42507H00

42507H01

42507B00

42507TOP

0.098"PITCH 180° PITCH WAFER DIP

0.098"Single wire end rubber shell

0.098"Single wire end rubber shell plug

0.098"Positioning buckle

0.098"Positioning buckle

PIN:1*2-1*8P H:17.00

PIN:1*2-1*8P H:9.50MM

PIN:1*2-1*8P H:10.50MM

PIN:1*2-1*8P H:7.80MM

Material：Phosphor Bronze Plating：Au or Sn

View details View details View details View details View details

42508W00

42508W00-B2

42508W00

42508W90

42508W90-A2

0.098"180°Dual WAFER DIP TYPE

0.098"180°Dual WAFER DIP TYPE Solder joint

0.098"180°WAFER SMT TYPE

0.098"90° Dual WAFER DIP TYPE

0.098"Dual Horizotal SMT Type WAFER

PIN:2*2P-2*16P H:10.51MM

PIN:2*2-2*8P H:10.51MM

PIN:2*2-2*16P H:9.14MM

PIN:2*2-2*16P H:9.14MM

PIN:2*2-2*8P H:9.49MM

View details View details View details View details View details
