Product Code:
42503W00Order(MOQ):
3000Product Specifications:
0.098"180°PITCH WAFER DIPProduct Origin:
Xiamen City, China.Color:
Red, yellow, blue, green, brown, black, white, greyShipping Port:
Xiamen port, China.Lead Time:
Within 7-10 working days as soon as we received the deposit./js/htmledit/kindeditor/attached/20240826/20240826201453_42242.jpg
Spec:2.5mm PITCH 180° PITCH WAFER DIP
Poles:1*3~1*4
Rated Current:4.6A AC DC
Rated Voltage:250V AC DC
Contact resistance:20mΩ Max
Insulation resistance:1000MΩ Min
Withstand Voltage:1500V AC/minute
Temperature Range:-55℃~+105℃
