5.08MM(.200")
45801

43812TOP

  • Product Code:

    43812TOP
  • Order(MOQ):

    3000
  • Product Specifications:

    0.200 amphenol connector
  • Product Origin:

    Xiamen City, China.
  • Color:

    Red, yellow, blue, green, brown, black, white, grey
  • Shipping Port:

    Xiamen port, China.
  • Lead Time:

    Within 7-10 working days as soon as we received the deposit.

/js/htmledit/kindeditor/attached/20240823/20240823081335_90508.jpg

Spec:5.08mm PITCH TERMINAL
Wrie Range:AWG#28~#24 AWG#24~#20 AWG#16~#20 AWG#14~#16
Insulation O.D.:0.8mm-1.4mm  1.2mm-2.6mm 1.8mm-2.8mm 2.4mm-3.4mm
Material:Phosphor Bronze
Plating:Au or Sn
Rated Current:8A AC DC
Rated Voltage:250V AC DC
Contact resistance:15mΩ Max
Insulation resistance:100MΩ Min
Withstand Voltage:1500V AC/minute
Temperature Range:-55℃~+105℃
