Product Code:
33812TOPOrder(MOQ):
3000Product Specifications:
0.200 180°Dual WAFER DIP TYPEProduct Origin:
Xiamen City, China.Color:
Red, yellow, blue, green, brown, black, white, greyShipping Port:
Xiamen port, China.Lead Time:
Within 7-10 working days as soon as we received the deposit./js/htmledit/kindeditor/attached/20240822/20240822190938_27122.jpg
Spec:5.08mm PITCH TERMINAL
Wrie Range:AWG#28~#24 AWG#24~#20 AWG#16~#20 AWG#14~#16
Insulation O.D.:0.8mm-1.4mm 1.2mm-2.6mm 1.8mm-2.8mm 2.4mm-3.4mm
Material:Phosphor Bronze
Plating:Au or Sn
Rated Current:8A AC DC
Rated Voltage:250V AC DC
Contact resistance:15mΩ Max
Insulation resistance:100MΩ Min
Withstand Voltage:1500V AC/minute
Temperature Range:-55℃~+105℃
