Product Code:
45701TOPOrder(MOQ):
3000Product Specifications:
0.224 TERMINALProduct Origin:
Xiamen City, China.Color:
Red, yellow, blue, green, brown, black, white, greyShipping Port:
Xiamen port, China.Lead Time:
Within 7-10 working days as soon as we received the deposit./js/htmledit/kindeditor/attached/20240822/20240822155808_37166.jpg
Spec:5.7mm PITCH TERMINAL
Wrie Range:AWG#15~#16 AWG#12
Insulation O.D.:1.5mm 4.0/2.5mm
Material:Phosphor Bronze
Plating:Au or Sn
Rated Current:3A AC DC
Rated Voltage:600V AC DC
Contact resistance:10mΩ Max
Insulation resistance:1000MΩ Min
Withstand Voltage:2200V AC/minute
Temperature Range:-40℃~+105℃
