3.00MM(.118")
23001AWR

23001AWLC

  • Product Code:

    23001AWLC
  • Order(MOQ):

    3000
  • Product Specifications:

    0.118"90°WAFER SMT TYPE column buckle
  • Product Origin:

    Xiamen City, China.
  • Color:

    Red, yellow, blue, green, brown, black, white, grey
  • Shipping Port:

    Xiamen port, China.
  • Lead Time:

    Within 7-10 working days as soon as we received the deposit.

/js/htmledit/kindeditor/attached/20240906/20240906081406_69824.jpg

Spec:3.00mm PITCH 90° WAFER SMT TYPE
Poles:02-12
Contact resistance:20mΩ Max
Insulation resistance:1000MΩ Min
Rated Voltage:250V AC DC
Rated Current:5.0A AC DC
Withstand Voltage:1000V AC/minute
Temperature Range:-25℃~+85℃
