5.08MM(.200")
Home /

Pin Header

/

5.08MM(.200")

/

KDPH-0125

KDPH-0125

KDPH-0125

  • Product Code:

    KDPH-0125
  • Order(MOQ):

    3000
  • Product Specifications:

    0.200"Pin Header,Dual Plastic,Single Row,DIP
  • Product Origin:

    Xiamen City, China.
  • Color:

    Red, yellow, blue, green, brown, black, white, grey
  • Shipping Port:

    Xiamen port, China.
  • Lead Time:

    Within 7-10 working days as soon as we received the deposit.

/js/htmledit/kindeditor/attached/20240827/20240827142107_70539.jpg

Spec:Pitch5.08mm Pin Header,Dual Plastic,Single Row,DIP
Pins:1*1-1*20
Plastics Height:3.2MM
Rated Voltage:250V AC DC
Rated Current:7A AC DC
Contact resistance:20mΩ Max
Insulation resistance:500MΩ Min
Withstand Voltage:1000V AC/minute
Temperature Range:-40℃~+105℃
