Product Code:
KDBH-0005Order(MOQ):
3000Product Specifications:
0.050"box header,SMTProduct Origin:
Xiamen City, China.Color:
Red, yellow, blue, green, brown, black, white, greyShipping Port:
Xiamen port, China.Lead Time:
Within 7-10 working days as soon as we received the deposit./js/htmledit/kindeditor/attached/20240904/20240904133832_15970.jpg
Pitch:1.27MM
Type: SMT
Row: Dual
Pins:2*5~2*50
Plastics Height:5.4MM
Rated Voltage:250V AC DC
Rated Current:1A AC DC
Withstand Voltage:500V AC/minute
Contact resistance:20mΩ Max
Insulation resistance:1000MΩ Min
Temperature Range:-40℃~+105℃
